La nuova generazione è arrivata. E' piccola e potente.

Product Highlights

• Highest power density on the market
• Smallest & lightest product on the market - saves cabinet space & cost
• Speeds up test times
• High functionality - suitable for many applications
• Versatile communication protocols
• Simplifies control

• 1U benchtop and  19Inch standard rack package
• Constant voltage, constant current and constant power modes
• Internal resistance programming function

• LAN (LXI 1.5), USB and RS232/485 built in as standard
• Integrated Anybus CompactCom interface platform
• Isolated analogue remote control and monitoring
• Communications compatible with Z+ and Genesys

• Arbitrary waveform (up to 100 steps) generation and storage
  (4 storage locations)
• Fast programming response time with user adjustable voltage and current slew rate
• Two user programmable output control pins (open drain) to activate external devices
• Easy auto-configuration for parallel systems up to 20kW
• Safe or Auto re-start and last settings memory

• Variable speed fan (monitors load and ambient temperature)
• Efficiency up to 93%
• 3 phase 170 to 265Vac, 342 to 460Vac or wide range 342 to 528Vac input options

• High contrast, wide viewing angle LCD display with brightness and dimming control
• Blank front panel option

• 5kW Output power in 1U
• Output voltage range: 10V up to 600V
• Output current range: 8.5A to 500A
• Input voltage range:
  3 Phase 200: 170V~265Vac
  3 Phase 400: 342V~460Vac
  3 Phase 480: 342V~528Vac
• light weight, less than 7kg
• 19” 1U chassis, Depth: 441.5mm
• 5 year warranty

• Test and measurement
• Component testing and burn-in
• ATE
• Automotive
• Automation
• laser diodes
• Battery simulation
• Renewable energy
